We are aiming to be nominated from companies around the world
We consider the inspection of our production to be the most important part
of our business since it is the key to successful mass production. Our
classification and analysis of the defects gives us further improvement of
our products and eliminates defects.
Our staff training lets us analyze the best placement depending on what they
are good at and improves their skills to provide a high quality product.
Company Profile
| Company Name | Plot Work Co., Ltd. |
| Established | November 1996 |
| Capital | ¥ 10,000,000 |
| Number of Employees | 30 people |
| Average age | 30 years old |
| Business | Plastic Prototype / Sample design to pre-manufacture model Various gear / Manufacturing and Measuring Ｖａｃｕｕｍ casting 3D Printing Plastic resin processing / Post processing Surface plating, printing and painting Production of spare parts Metal Prototype with aluminum or other material Die-cast aluminum Three-dimensional metal machining Stamping mold / progressive to single die Small lot demo production Metal die Various metal machining / prototype to mass production Metal stamping / prototype to mass production Stamping die / progressive to single die Polishing and other surface finish Other Jig / inspection, prototype to mass production CAD・CAM data service Measurement service Design service |
| Representative | President and CEO Tsunenoshin Tamura |
| Address |
Minamiterakata Minamidori 1-5-26 Moriguchi-shi Osaka 570-0044 Ｊａｐａｎ Link to map |
| Phone | +81-6-6993-6361 |
| Fax | +81-6-6993-6362 |
| info@plot.jp | |
| Web site |
■Webseite auf Deutsch ■Plastic Processing ■Metal Machining ■Representative's’ Blog |
Equipment
| List of equipment | |||
| Machine Model | Size | Number | Note |
| machining center | 600*600 | 9 | Aichi Factory (2) |
| Large machining center | 600*1000 | 3 | |
| 3-axis machining center (MAZAK Inc.) |
550*1050 | 1 | |
| 5-axis machining center (DMG Inc.) |
φ500 | 1 | |
| 5-axis machining center (DMG Inc.) |
φ650 | 1 | |
| Drilling Robot | 400*700 | 4 | |
| Lathe | Can be processed up to160φ | 1 | |
| 3D-CAD | 3 | ||
| 3D-CAD/CAM | 10 | ||
| 4D-CAD/CAM | 1 | ||
| Carving machine | 3 | ||
| Milling machine | 1 | ||
| Drilling machine | 2 | ||
| Lifting board | 2 | ||
| Blasting machine | 400*500 | 1 | |
| Casting machine | 1 | ||
| Thermostatic machine | 4 | ||
| Three-dimensional measuring instrument |
1 | ||
| Three-dimensional image measuring instrument |
2 | ||
| Microscope | 1 | ||
| CAD/CAM | 3D Tascal X (3D High spec viewer) |
| Quick
Scope image measurement equipment (CNC, AF,proof ring) |
Drive system | CNC |
| Measurement range | 200 X 200 X 100 （mm） | |
| Measurement units | Reflective linear encoder | |
| Image detection system | High sensitivity CCD color camera | |
| The amount of the minimum display | 0.5μm | |
| Measurement accuracy | Axis XY (2.5 +6 L/1000) μm Axis Z (5 +6 L/1000) μm |
|
| Driving speed | 50mm / s maximum |
| Stereo
zoom microscope (X • Y stage tool) + Digimatic Micrometer head X2 |
Total magnification | 10x (φ23 mm) ~ 44x (φ5.2 mm) |
| Working distance | 90mm | |
| Work height can be observed | 130mm | |
| Measurement range | 25.0 X 25.0 (mm) | |
| Measurement accuracy | 0.001mm |
| Measuring range (mm) | Best measurement capability (mm) | |
| Digimatic caliper | 200 | 0.001 |
| 300 | 0.001 | |
| 600 | 0.001 | |
| Dial caliper | 150 | 0.02 |
| Digimatic micrometer | 25 | 0.001 |
| 50 | 0.001 | |
| Digital point Micrometer |
25 | 0.001 |
| Inside
type micrometer caliper |
30 | 0.001 |
| Digimatic indicator | 25 | 0.001 |
| Dial
test indicator Gauge |
300 | -------- |
| Pin gauge | 0.05〜1.00 1.00〜15.00 |
0.01 0.01 |
| Ceramic block gauge | 32 | 0.005 |
